8.00 Technical specications
8.01 Module label, quick info
A module label on the strap relief indicates which optional modules are built
into the specic GH3 lifting module together with a clear indication of the Safe
Working Load.
SWL 350 kg/770 lbs
Service
Module
CLM
Module
Scale
Module
WiFi
Module
Class III
Scale
Module
Trainer
Module
8.02 Conguration of GH3 lifting module
Basic conguration
The GH3 lifting modules are congured in a large number of variants. The 6
rst columns in the chart below describes the basic conguration: ceiling hoist
family, specic type, Safe working load, number of lifting straps, number of
lifting motors, number of horizontal drive motors.
Options
The options of the hoist (IR remote, service module, scale module etc) can
be chosen where applicable. All applicable options are indicated in the chart
below.
Conguration code
The nal conguration of the options is indicated by a conguration code,
for example 7C. The code is found on the serial number label, lifting module
(page 49).
Use our Product Information App on smartphones to translate the code into
conguration details. Download the app here: https://productinformation.guld-
mann.com. The app will also run on Chrome browser.
