Guldmann GH3 - Special Components, Maintenance, and Service; Special Rail System Components; Combi-lock, automatic

46
© Guldmann GB/US-02/2021 • # 550216_19
© Guldmann GB/US-02/2021 • # 550216_19
Turntable
The turntable is used in rail systems where
the hoist needs to run in several directions.
The turntable must not be used with the
GH3 Twin hoist.
The GH3 hoist is placed in the center of the
turntable. By pressing the switch, the turntable
rotates 90°. Press again, and the turntable
returns to the rst position.
Safety
This product is mechanically protected against
derailing and jamming.
Positioning lock
The Positioning lock adds yet another option to the Guldmann GH3 ceiling
hoist system for moving, treating, mobilising and rehabilitating people.
Using the Positioning lock, it is possible to secure the lifting module and/or
the traverse rail in a given position in the full-coverage rail system.
Securing the lifting module in this way allows it to be used for the rehabilita-
tion and retraining of both bed-bound and more mobile users.
Combi-lock, automatic
Intended use
The Combi-lock is used to move a
person from one rail system to another.
Purpose
Use the Combi-lock when connecting
one rail system to another.
The Combi-lock enables a secure
connection to be made between two
rail systems, e.g. when operating
from a single-track rail system in the
bedroom to a room-covering system
in the bathroom.
