GW Instek GPP-2323 User Manual

BASIC OPERATION
57
Min
Value
Press the F4 (Min Value) button. The
setting on LCD will be activated and
appears in red front color. Use
number pad to set the parameters
directly and then press the F1 (V/A)
or the F2 (mV/mA) button to
confirm; or use arrow keys along
with scroll wheel to complete the
setting.
Start
Press the F5 (More) button and then
press the F1 (Start) button. The
setting on LCD will be activated and
appears in red front color .
Use number pad to set the
parameters directly and then press
the F1 (Done) to confirm; or use
arrow keys along with scroll wheel
to complete the setting.
Points
Press the F2 (Points) button. The
setting on LCD will be activated and
appears in red front color
. Use number pad to set
the parameters directly and then
press the F1 (Done) to confirm; or
use arrow keys along with scroll
wheel to complete the setting.
Interval
Setting the time interval of each
point of the current selected
template (i.e. the duration of output
of each set of timing parameters) ,it
can be set from 1s to 300s.
Press the F3 (Interval) button. The
setting on LCD will be activated and
appears in red front color
. Use number pad to set
