GW Instek GPP-2323 - Source Function

GPP Series User Manual
36
Source Function
Description
Each channel is equipped with basic power
functions and able to display both settings
and read back value of V/I as well as output
status
Parameter
description
Vset
Set output voltage of active channel.
The range is as the following:
CH1：0.000V-33.000V
CH2：0.000V-33.000V
CH3：0.000V-5.500V (GPP-4323)
CH4：0.000V-16.000V (GPP-4323)
Iset
Set limited current of active channel.
The range is as the following:
CH1：0.0000A-3.2000A
CH2：0.0000A-3.2000A
CH3：0.0000A-1.1000A (GPP-4323)
CH4：0.0000A-1.1000A (GPP-4323)
OVP
Set OVP. The range is as the
following:
CH1：0.5V-35.0V
CH2：0.5V-35.0V
CH3：0.5V-6.0V (GPP-4323)
CH4：0.5V-16.5V(GPP-4323)
