GPP Series User Manual
58
the parameters directly and then
press the F1 (Done) to confirm; or
use arrow keys along with scroll
wheel to complete the setting.
Inverted
Press the F4 (Inverted) button. On
(inverted) and Off (non-
inverted) appear on LCD
in turn. Simply stop at the status
which is required.
Construct
Construct
Press the F5 (Construct) to complte
construction.
Menu Tree
Description
User is able to well understand the overall
functions of Sequence via menu tree, which
is put in proper order by tiers. The Return
key is used for back to the parent menu. See
the construction below:
Advance
Sequence
Level1------------
Level2------------
Level3------ ......
Level4----
Set
Edit
Level5-------
Level6---------(...)
Done
Return
Cycles No. ......
