GPP Series User Manual
46
Output rating Rating 0 - 32V/0 - 6A
Operation
1. Press F4 or F5 button for operating the
corresponding Parallel to enter the tracking
parallel function. Yellow PAR will be shown on
the status area.
2. Press CH1 button to proceed to CH1/CH2
voltage/current setting.
4. For setting operation of parameter, refer to page
37.
Output
The button ON/OFF of CH1/CH2 is individually
available, while All ON/OFF button is available
for all channels.
CAUTION: under tracking parallel mode, CH1 is master, whilst
CH2 is slave. Thus, output voltage/current setting is Not available for
CH2.
Load Function
Description
CH1/CH2 of the GPP-1326/2323/3323/4323
series can be set to the Load Mode function,
under which both tracking series and tracking
parallel function are Not available.
