GW Instek GPP-2323 User Manual

BASIC OPERATION
67
(Decline). Base Time is for setting
time of initial Group. Step is for
setting time interval of neighboring
Group.
Parameter
Setting
No.
Under the Delay function, press the
F2 (Edit) button followed by
selecting the F1 (No.). The setting on
LCD is activated and appears in red
font color . Use number
pad to set the parameters directly
and then press the F1 (Done) button
to confirm; or use arrow keys along
with scroll wheel to complete the
setting. The F4 (Page Up)key and F5
(Page Down) key can jump directly
to the previous or next page,each 8
groups is a Page.
State
Under the Delay function, press the
F2 (Edit) button, and then the F2
(State) button followed by selecting
F1 (On), F2 (Off) or F3 (Inverted) to
set output On/Off status of each
group. Press the F4 (Last) key for
the previous one and the F5 (Next)
key for the next one
Time
Under the Delay function, press the
F2 (Edit) button followed by
selecting the F3 (Time). The setting
on LCD is activated. Use number
pad to set the parameters directly
and then press the F1 (Second)
button to confirm; or use arrow
keys along with scroll wheel to
complete the setting. Press the F4
(Last) key for the previous one and
the F5 (Next) key for the next one.
