GPP Series User Manual
78
group number. The setting on LCD
is activated and appears in red font
color. Use number pad to set the
parameters directly and then press
the F1 (Done) button to confirm; or
use arrow keys along with scroll
wheel to complete the setting.
Press the Advance key on control
panel. Select the F5 (Recorder)
function. Press the F3 (Channel)
button to enter setting of recorded
channel. F1 (CH1), F2 (CH2), F3
(CH3), F4 (CH4) are available for
selection. The numbers of channel
may vary by models.
Press the Advance key on control
panel. Select the F5 (Recorder)
function followed by pressing F4
(Memory) button to setting of
recorded saving. Recorded data can
be stored in internal memory or
external USB Flash.
1. Press right arrow button to enter the
list of 10 groups. Rotate the scroll
wheel (Encode) to select target file.
Also rotate the scroll wheel (Encode)
to enter the flash drive when
necessary.
To Next Page
