REMOTE CONTROL
99
RS-232
Description
The GPP series models can be remotely
controlled by RS-232 connection.
Interface
Rear panel RS-232 port
Connection
Under power-off state, connect RS-232 cable
and select RS-232 port in the Interface. The
message USB232 will appear gray in the status
bar when connection, and turns to white color
while the first command connects succesfully.
Panel control will be automatically under lock
state when connection is successful.
Parameter
Setting
Press the System button followed by pressing
the F1 (Interface) button to select the target port:
F1 (RS-232). The setting of baud rate will appear
automatically, please then choose desired
setting.
Display
The parameter information of RS232 will appear
on LCD. Refer to the description below:
8 --->data bit 8bit
N --->no parity bit
1 --->stop bit 1bit
N --->no flow control bit
