APPLICATION EXAMPLES
Reference Signal for PLL System
Description
The SFG output can be used as a cost-effective reference
signal for Phase-Locked-Loop system. Directly connect
SFG output to PLL input.
Block diagram
SFG series
PLL
Reference In Output
Trouble-Shooting Signal Source
Description
The SFG output can be used as the signal source to test
the failed part in a circuit system. Isolate the problematic
part from the rest, feed the SFG output as a stimulus,
and observe the outcome using an oscilloscope.
Block diagram
SFG series
Oscilloscope
Circuit System
