APPENDIX
Error Messages
Frequency
error
FrEq-Err1
Sine and square wave frequency over range.
This message appears when entering sine or
square waveform frequency larger than the
rating. See page26 for sine/square rating.
FrEq-Err2
Triangle wave Frequency over range. This
message appears when entering triangle
waveform frequency larger than 1MHz. See
page
26 for triangle wave rating.
FrEq-Err3
FM Center Frequency over range. This
message appears when trying to enter FM
center frequency larger than specified. See
page38 for FM center frequency range.
Duty Cycle
error
duty-Err1
Not square waveform. This message
appears when trying to set duty cycle in
non-square (=sine or triangle) waveform.
For duty cycle setting, see page28 (square
wave) or page33 (TTL/CMOS output).
duty-Err2
Square wave frequency over range. This
message appears when trying to set duty
cycle when the square wave frequency is
over 1MHz. For square wave frequency
setting, see page
26.
duty-Err3
Duty over range. This message appears
when the duty cycle setting goes outside
20~80% range.
For duty cycle range, see page28 (square
wave) or page33 (TTL/CMOS output).
