APPENDIX
53
Specification
Output Function Sine, Square, Triangle
Amplitude Range
10Vp-p (into 50Ω load)
Impedance
50Ω ± 10%
Attenuator
−20dB ± 1dB x2
DC Offset < −5V ~ >+5V (50Ω load)
Duty Range 20% ~ 80%, 2Hz~1MHz (Square Wave)
Duty Resolution 1% (Square Wave Only)
Main
Display 9 digits LED display
SFG-2004 0.1Hz ~ 4MHz
SFG-2007 0.1Hz ~ 7MHz
SFG-2010 0.1Hz ~ 10MHz
SFG-2020 1Hz ~ 20MHz
SFG-2104 0.1Hz ~ 4MHz
SFG-2107 0.1Hz ~ 7MHz
SFG-2110 0.1Hz ~ 10MHz
Sine/Square
Waveform Range
SFG-2120 1Hz ~ 20MHz
Triangle
Waveform Range
0.1Hz ~ 1MHz
(1Hz ~ 1MHz for SFG-2020/2120)
Resolution 0.1Hz (1Hz for SFG-2020/2120)
Stability ±20ppm
Accuracy ±20ppm
Frequency
Aging ±5ppm/year
Harmonic
Distortion
≥−55dBc, 0.1Hz ~ 200kHz
≥−40dBc, 0.2MHz ~ 4MHz
≥−30dBc, 4MHz ~ 20MHz
(Amplitude at maximum position
without attenuating 1/10 of any
combination setting, TTL/CMOS off)
Sine Wave
Flatness
< ± 0.3dB, 0.1Hz ~ 1MHz
< ± 0.5dB, 1MHz ~ 4MHz
< ± 2dB, 4MHz ~ 10MHz
< ± 3dB, 10MHz ~ 20MHz
(At the max amplitude relating to 1kHz)
Triangle Wave
Linearity
≥ 98%, 0.1Hz ~ 100kHz
≥ 95%, 100kHz ~ 1MHz
Symmetry ±1% of period + 4ns, 0.1Hz ~ 100kHz
Square Wave
Rise/Fall Time ≤ 25ns at maximum output (50Ω load)
Level 4 ± 1Vpp ~ 15 ± 1Vpp, adjustable
CMOS Output
Rise/Fall Time
≤ 120ns
