GW Instek SFG-2000 Series User Manual

SFG-2000 Series User Manual
54
Level
≥ 3Vpp
Fan Out 20 TTL Load
TTL Output
Rise/Fall Time
≤ 25ns
Sweep Rate 100:1 Ratio Max, adjustable (Note1)
Sweep Time 1 ~ 30s, adjustable (Note2)
Sweep
(SFG-2100
Series)
Sweep Mode Linear, Logarithmic
Depth 0 ~ 100%
Frequency 400Hz (internal), DC ~ 1MHz (external)
Carrier BW
100Hz ~ 5MHz (−3dB)
Amplitude
Modulation
(SFG-2100
Series)
External
Modulating
Sensitivity: ≤ 10Vpp for 100%
modulation
Deviation
≥0 ~ ±50kHz, center at 1MHz
Frequency
400Hz fixed (internal), 1kHz fixed
(external)
Frequency
Modulation
(SFG-2100
Series)
External
Modulating
Sensitivity: ≤ 10Vpp for 10%
modulation (center at 1MHz)
Range 5Hz ~ 150MHz
Accuracy Time Base Accuracy ± 1 count
Time Base ±20ppm (23±5°C) after 30min warmup
Max. Resolution 100nHz for 1Hz, 0.1Hz for 100MHz
Input Impedance
1MΩ/150pf
Frequency
Counter
(SFG-2100
Series)
Sensitivity
≤ 35mVrms, 5Hz ~ 100MHz
≤ 45mVrms, 100MHz ~ 150MHz
Store/Recall
10 Groups of Setting Memories
Power Source
AC115V/230V +10%, −15%, 50/60Hz
Operation
Environment
Indoor Use, Altitude Up to 2000m
Ambient Temperature 0 ~ 40°C
Relative Humidity ≤ 80%, 0 ~ 40°C
Relative Humidity ≤ 70%, 35 ~ 40°C
Install Category II / Pollution Degree 2
Storage
Environment
Temperature: −10 ~ 70°C
Humidity: ≤70%
Accessories
Instruction Manual x 1, Power Cord x 1
GTL-101 x 2 (SFG-2100 Series)
GTL-101 x 1 (SFG-2000 Series)
Dimension 107 (W) x 266 (H) x 293 (D)
General
Weight
Approx. 3.2kg (SFG-2100 Series)
Approx. 3.1kg (SFG-2000 Series)
Note1: In order to get the maximum sweep span, sweep time needs to be tuned.
Note2: If sweep time is too long, the stop frequency will stay at the maximum
frequency until the end of the sweep cycle.
