11
Figure 16 Logical drive detail screen
Table 5 Parameter description
ID Logical drive number. Options include
0
and
1
.
Name Logical drive name.
Status
Logical drive status. Options include:
• Functional.
• Degrade.
• Offline.
BGA Type
Background task type. Options include:
• Initialization—RAID initialization in progress.
• Rebuild—RAID rebuilding in progress.
• MediaPatrol—Media patrol for logical drives in progress.
• None.
BGA Status
Background task status. Options include:
• None.
• RUNNING—Task progress in percentage.
Member Count Number of member drives.
Member ID Member drive ID.
Stripe Block Stripe size.
Size Logical drive capacity.
Configuring logical drive media patrol
This feature is available only when RAID 1 is configured.
To configure logical drive media patrol:
1. Access the storage controller configuration screen, select Virtual Device Information, and
press Enter.
