Figure 14 Pump tubing preparation

1 To intake tubing 4 Length for controller with standard liquid

detector

2 Alignment dots 5 Length for controller with optional non-

contacting liquid detector

3 To fitting on sampler base 6 Length inside the pump

22 English
