Specification Standard base Compact base Composite base
Strainers 316 stainless steel in standard size, high velocity or low profile for shallow depth
applications and Teflon
®
or 316 stainless steel in standard size.
Sample bottle
capacity
1-L (33.8 oz) polyethylene
and/or 350-mL (11.83 oz)
glass bottles (24x)
2.3-L (0.6 gal) polyethylene
and/or 1.9-L (0.5 gal) glass
bottles (8x)
3.8-L (1 gal) polyethylene
and/or 3.8-L (1 gal) glass
bottles (4x)
3.8-L (1 gal) polyethylene
and/or 3.8-L (1 gal) glass
bottles (2x)
21-L (5.5 gal) or 15-L (4 gal)
polyethylene composite bottle
or 20-L (5.25 gal) polyethylene
or 10-L (2.5 gal) polyethylene
or 10-L (2.5 gal) glass (1x)
575-mL (19.44 oz)
polyethylene bottles
(24x)
950-mL (32.12 oz) glass
bottles (8x)
10-L (2.5 gal)
polyethylene bottle (1x)
10-L (2.5 gal) glass
bottle (1x)
21-L (5.5 gal)
polyethylene bottle
(1x)
3.2 AS950 controller
Specification Details
Dimensions (W x H x D) 31.1 x 18.9 x 26.4 cm (12.3 x 7.4 x 10.4 in.)
Weight 4.6 kg (10 lb) maximum
Enclosure PC/ABS blend, NEMA 6, IP68, corrosion and ice resistant
Pollution degree/installation
category
3, II
Protection class II
Display ¼ VGA, color
Power requirements 15 VDC supplied by a 8754500 power supply (110–120 or
230 VAC, 50/60Hz); 12 VDC supplied by an external battery
Overload protection 7 A, DC line fuse for the pump
Operating temperature 0 to 50 °C (32 to 122 °F)
Storage temperature –30 to 60 °C (–22 to 140 °F)
Storage/operating humidity 100% condensing
Pump Peristaltic high speed with spring-mounted Nylatron rollers
Pump enclosure Polycarbonate cover
Pump tubing 9.5 mm ID x 15.9 OD mm (
3
/
8
-in. ID x
5
/
8
-in. OD) silicone
Pump tubing life 20,000 sample cycles with: 1 L (0.3 gal) sample volume, 1 rinse, 6-
minute pacing interval, 4.9 m (16 ft) of
3
/
8
-in. intake tube, 4.6 m
(15 ft) of vertical lift, 21 °C (70 °F) sample temperature
4 English
