Figure 2 Latch plates alignment
4.3 Product components
Make sure that all components have been received. Refer to Figure 3. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately.
Figure 3 Product components
1 Base (Standard, compact or composite) 7 AC power supply (optional)
2 Components for a single-bottle option (bottle
and support can change)
8 Strainer
3 Center section with controller 9 Intake tubing, vinyl or Teflon-lined
4 Battery (optional) 10 Components for a multiple-bottle option
(bottles and retainers can change)
5 Top cover 11 Tubing coupler (Supplied with controllers
with the non-contacting liquid detector only.)
6 Battery charger (optional)
English 9
