4.2 Product overview
D A N G E R
Chemical or biological hazards. If this instrument is used to monitor a treatment process
and/or chemical feed system for which there are regulatory limits and monitoring
requirements related to public health, public safety, food or beverage manufacture or
processing, it is the responsibility of the user of this instrument to know and abide by any
applicable regulation and to have sufficient and appropriate mechanisms in place for
compliance with applicable regulations in the event of malfunction of the instrument.
C A U T I O N
Fire hazard. This product is not designed for use with flammable liquids.
The portable sampler collects liquid samples at specified intervals and keeps the samples in bottles.
Use the sampler for a wide variety of aqueous sample applications and also with toxic pollutants and
suspended solids. Set up the sampler with different retainers or bottles. Refer to Figure 1.
Figure 1 Product overview
1 Compact base 7 Pump
2 Standard insulated base 8 Controller
3 Center section 9 Liquid detector
4 Power source 10 Non-contacting liquid detector
5 Top cover 11 Composite insulated base for one 21-L
(5.5 gal) bottle
6 Controller connections
4.2.1 Close the cover
To close the cover, align the latch plates as shown in Figure 2 and close the latches.
8
English
