Page 89
21. Sampler Fill (if configured in the system). Signal to fill the BioTector sampler. To test the Sampler Fill
signal, press the ENTER key, set the device to ON/OFF, and press the ENTER key again. If the device is
on, it will be marked with an “*”. This signal remains on until turned off.
22. Sampler Empty (if configured in the system). Signal to empty the BioTector sampler. This signal is a 5
second pulse. To test the Sampler Empty signal, press the ENTER key to set the device ON.
23. Sampler Error (if configured in the system). Signal sent from the BioTector sampler indicating that
there is an error in the sampler. To test the Sampler Error signal, press the ENTER key, set the device to
ON/OFF, and press the ENTER key again. If the device is on, it will be marked with an “*”.
24. Sample Sensor (if configured in the system). This device is input only and therefore its state cannot be
changed from this menu. It only indicates the state of the Sample Sensor.
25. Leak Detector (if configured in the system). This device is input only and therefore its state cannot be
changed from this menu. It only indicates the state of the BioTector Liquid Leak Detector alarm input.
26. Reactor Purge. This function purges the Mixer Reactor. When activated, system automatically displays
the Reactor Purge menu, which contains the relevant reactor purge parameters.
27. Run Reagents Purge. This function primes all reagents in the BioTector.
29. Input/Output Status. Input/Output Status is a link to Maintenance, Diagnostics, Input/Output Status
menu (see Section 8.1.5 Input/Output Status).
