Installation
Figure 30 Network connector components
1 Housing, network connector 7 Insert, plastic label (network connector housing)
2 Network connector printed circuit board with shell bottom 8 Not used
3 Shell, top 9 Plug, rubber, cord grip
4 Screws, self-tapping (2x) 10 Seal, cord grip (2x)
5 Clamp, network cable(s) 11 Cord grip (2x)
6 Screw, pan head
