5
2. Quick start
For the first time of use and in case the unit has been not used for a while, fully charge the
internal battery.
2-1. Turning the unit ON / OFF
(1) Connect the probe to the probe connector so that
the polarity mark will be placed under
mark as shown in the right (12 o’clock).
(2) Press the power button to turn the unit OFF.
(3) When Smartdop is turned ON first time, the
message as shown in the picture right will
appear, press Enter button to proceed.
(4) When battery is low, low battery indicator
appears as shown in the right. Smartdop can be
used for a few more minutes. Recharge the
battery as soon as possible for further use.
Low battery
Polarity mark
Power button
Enter button
Right button
Back button
