3-2. Mode settings
Note: For the mode settings for options, see “§ 5-2-5. Menu for PPG” and “§ 5-3-5. Menu for
PV”.
3-2-1. Basic Modes
Smartdop has following five Basic Operation Modes:
• Blood Velocity - Measurement For measuring blood velocity
• Blood Velocity - Freeze For observing waveforms and numerical data
• Fetal Heart Rate - Measurement For measuring fetal heart rate
• Fetal Heart Rate - Freeze For observing heart rate and graph
• Menu For changing other mode settings
Changing Basic Mode with probe connection (Blood Velocity / Fetal Heart Rate)
Connecting 4, 5, 8 or 10 MHz probe sets on Blood Velocity mode automatically.
Connecting 2 MHz probe sets on Fetal Heart Rate mode automatically.
Optional operation modes are available by connecting optional PPG and PV probes. See
" 5. Options".
Changing mode with probe button (Measurement / Freeze)
Press the probe button to go to freeze mode and
press again to get back to measurement mode.
(When PRB-KEY is Freeze mode.)
With 2 MHz probe, Fetal Heart Rate mode, pressing
Right button also changes the mode alternatively.
