Monitoring heart rate in graph (WAVE mode, Monitoring mode)
(1) The measurement range of heart rate is 60 to 220 BPM.
(2) Heart rate at the moment is displayed on bottom left of LCD.
(3) Heart mark indicates the same way as DATA
mode. See previous page.
(4) Two dotted lines indicate Upper and Lower
limits of heart rate. If it gets out of limits for
more than 30 sec, LCD will start flashing for
warning.
(5) When on freeze mode by pressing probe or
Right button, the latest monitoring waveform
of up to 33 minutes can be shown over 4
pages on LCD with FREEZE indicator. Turn
Shuttle Button down to show next page.
(Approx. 8 minutes a page)
(6) The read out waveform from memories is
displayed with memory number, e.g. "#01" on
top right LCD.
