LIST OF FIGURES
Number Title Page
Figure 1. Pump Panel Identification Plate (Placard) ....................................................................... 5
Figure 2. Pump Serial Number Locations ........................................................................................ 6
Figure 3. Pump Model Codes ........................................................................................................... 6
Figure 4. Hale Booster Pump Inlet And Outlet ................................................................................. 9
Figure 5. Visually Determining Engine Or Opposite Engine Rotation .......................................... 10
Figure 6. Typical Booster Pump Mounting .................................................................................... 12
Figure 7. Grade 5 And Class 8.8 Bolt Marking ............................................................................. 13
Figure 8. Grade 8 And Class 10.9 Bolt Marking ........................................................................... 14
Figure 9. Check Gearbox Oil Level ................................................................................................. 16
Figure 10. Gearbox Drain ............................................................................................................. 24
Figure 11. Fill Gearbox With Fluid ................................................................................................ 25
Figure 12. Fluid Level ................................................................................................................... 25
Figure 13. Loss Of Suction Fault Flow Chart ............................................................................... 28
Figure 14. Cavitation Fault Flow Chart ........................................................................................ 30
LIST OF TABLES
Number Title Page
Table 1. Hale Flex Series Single Stage Booster Pump Drawings .................................................. 9
Table 2. Flex Series Inlet And Discharge Connections ............................................................... 14
Table 3. Preventive Maintenance Plan and Schedule ................................................................ 21
Table 4. Fluid Change Tools And Consumables List ................................................................... 24
Table 5. Recommended Gearbox Lubricant ................................................................................ 26
Table 6. Loss Of Suction SCR Table ............................................................................................. 29
Table 7. Cavitation SCR Table ...................................................................................................... 31
FSG–MNL–00183 REVISION HISTORY
CHANGE
DATE
AFFECTED PAGES
Revision A 15 January 2019 All – Initial Release
Revision B 8 May 2019
Cover (graphic), 1,10,28,29,30 (website URL), 13 (Hardware),
14 (Sealant), 23 (Pump Vacuum Test), 24 (Triennial Pump
Maintenance), 26 (Recommended Gearbox Lubricants)
