TECHNICAL SPECIFICATIONS
2
2.2
PERFORMANCE DATA
2.1
GAS CATEGORIES AND
APPLIANCE CLASSIFICATION
The Seasonal Efficiency (SEDBUK) conforms to Band D. The efficiency value is used in the
UK Government Standard Assessment (SAP) for energy rating of dwellings.
The appliance meets the essential requirements for Gas Appliance
(90/396/EEC) and the Efficiency directive (92/42/EEC). It also
meets the directive 73/23/EEC relating to electrical equipment
designed for use within certain voltage limits and directive
89/336/EEC relating to electromagnetic compatibility.
The appliances were certified by the Notified Body 0087.
Any alterations to the appliance not approved by Halstead Boilers
Ltd could invalidate the certification, boiler warranty and may
infringe the current issue of statutory requirements.
The appliances are marked as category I2H for use on Natural
Gas (G20) only. The HERO 40 and 60 are also approved to I3P
and available as separate boilers.
As defined in EN 483 the appliance classification may be any of
the following depending on the chosen flue option:
C
12
:
concentric horizontal or
C
22: SE-duct
C
32: concentric vertical
2.3
CONNECTION SIZES
Gas connection Rc 1/2 “ BSP
CH connections 22 mm tail end
2.4
GENERAL SPECIFICATIONS
HERO
Heat
output
Heat
input
(gross)
Heat
input
(nett)
Burner
pressure
SEDBUK
30 40 40 P 50 60 60 P 75 90
kW 8.79 11.72 11.72 14.65 17.58 17.58 21.97 26.37
BTU/h 30000 40000 40000 50000 60000 60000 75000 90000
kW 10.85 14.47 14.47 18.1 21.7 21.7 27.2 32.6
BTU/h 37020 49372 49372 61757 74040 74040 92806 111231
kW 9.78 13.03 13.33 16.3 19.6 19.99 24.51 29.37
BTU/h 33369 44458 45495 55616 66875 68226 83628 100210
mbar 6.9 12.2 21.5 10.0 12.5 23 9.8 14.2
In.wg 2.8 4.9 8.6 4.0 5.0 9.2 3.9 5.7
% 79.36 79.08 80.89 78.54 79.29 80.87 78.4 78.6
HERO 30 40 40 P 50 60 60 P 75 90
Main burner
Injector mm ø 3.0 3.0 2.1 3.5 3.7 2.5 4.4 4.4
Minimum Water Flow Rate
l/min 11.45 15.27 15.27 19.09 22.90 22.90 28.66 34.37
(galls/min) (2.51) (3.36) (3.36 (4.20) (5.04) (5.04) (6.30) (7.56)
Total Water Capacity
Litres 1.75 1.75 1.75 1.75 1.75 1.75 2.6 2.6
galls 0.385 0.385 0.385 0.385 0.385 0.385 0.572 0.572
Pressure loss
(mH
2
O) 0.18 0.32 0.32 0.48 0.7 0.7 0.8 1.1
@ 11°C _T
Static Head
Max metres 30 30 30 30 30 30 30 30
ft 100 100 100 100 100 100 100 100
Total weight
kg 44.2 44.2 44.2 44.2 44.2 44.2 57.35 57.35
lb 97.44 97.44 97.44 97.44 97.44 97.44 126.4 (126.4
Lift Weight
kg 36 36 36 36 36 36 48.3 48.3
lb 79.37 79.37 79.37 79.37 79.37 79.37 106.5 106.5
Electricity supply 230V 230V 230V 230V 230V 230V 230V 230V
50Hz 50Hz 0Hz 50Hz 50Hz 50Hz 50Hz 50Hz
Power consumption
watts 70 70 70 70 70 70 85 85
Internal Fuse
Amps 44444444
External Fuse
Amps 33333333
Water protection rating 22222222
* Gas consumption
1/min 17.23 22.98 13.5 28.75 34.46 9.0 43.2 51.77
ft
3
/hr (36.49) (48.69) (28.59) (60.91) (73.02) (19.1) (91.02) (109.7)
Rear Horizontal Flue System
Restrictor Diameter [RF] mm (Rear Exit) 27 30 30 35 37 37 38 40
Vertical Flue System
Restrictor Diameter [UF] mm 28 34 34 38 42 42 43 45
CO
2
Value % 6.0 6.0 7.0 6.5 7.0 7.7 7.0 7.0
* Gas consumption based on using Natural Gas with a C.V of 37.78 MJ/m3. **Using Propane with a CV of 95.65 MJ/m3
