M.A.R.V.E.L. Installation Operation & Maintenance Manual
MARVELIO&M/022009/rev1/EN
Remove pressure transducer faceplate (4 screws).
5.
Remove side mount screws (2 screws).
6.
Replace with Halton Part # 18028).
7.
Reconnect wires and tubing as before. Check that the tubing is not kinked.
8.
5. Remove faceplate screws (4)
6. Remove mounting screws (2)
3. Disconnect wires
4. Disconnect ¼” AL tubing
