M.A.R.V.E.L. Installation Operation & Maintenance Manual
MARVELIO&M/022009/rev1/EN
M.A.R.V.E.L. System Components
Overview
A key feature of the M.A.R.V.E.L. system is fl exibility. It can be applied to a single hood – or over
multiple hoods – depending on the requirements.
FLOW
AIR
TS
FUSIBLE LINK
IR1
IR2 IR3
Exhaust Fan
PT
CONTROLLER
ST
VFD
CP
Figure 1: Single Hood M.A.R.V.E.L. Installation
