Hamilton Microlab STAR - Microlab STAR Pipetting Channels

Microlab
®
STAR User Manual
Page 26 of 225 610766/02
 $XWRORDG2SWLRQ
The Autoload option, like the options mentioned above, belongs to the Microlab STAR
configuration initially specified by the customer and cannot be added later.
The autoload unit is a device enabling automatic loading of the Microlab STAR. It contains a
loading head that
• moves in an X direction,
• shunts carriers onto and off the Microlab STAR, and
• reads the barcodes of carriers, tubes, and microtiter plates.
There is a presence sensor that identifies the tubes present on a carrier.
Barcode reading is only possible in conjunction with the Autoload option.
Equipped with autoload, the ML STAR can read the following barcode types:
- ISBT Standard
- Code 128 (Subset B and C)
- Code 39
- Codabar
- Code 2 of 5 interleaved
- UPC A/E
- JAN/EAN8
Barcode Reader
7KH$XWRORDGRSWLRQDQGEDUFRGHRULHQWDWLRQV
IRUWXEHVDQGSODWHV
