8.4 Command Trigger mode
Under this mode, engine start to read data after receiving the scan instruction from the host (that is “1” was written
into bit from zone bit 0x0002), and stop reading after data transmitted.
Attention: under this mode, trigger command instruction is: 7E 00 08 01 00 02 01 AB CD.
The engine receive the instruction, will output 7 byte responding first and start to read at the same time (responding
is :02 00 00 01 00 33 31).
Single reading time
Under this mode, it means the max time that engine identify the data, single reading time range is 0.1~25.5 second,
step size is 0.1 second, when it is “0”, means no limit on reading time, default time is 5 seconds.
