Hamlet HBCS2D100W User Manual

Appendix A: Default Settings Table
Parameter name
Default Setting
Remarks
Interface
TTL-232
Baud rate
9600
Check
NO
Data bits
8bits
Stop bits
1bits
Hardware flow
control
No hardware flow control
Mode parameter
Default read mode
Manual Read Mode
Serial trigger
mode
Single reading
time
5s
Parameter range:
0.1-25.5 seconds, the steps of 0.1s;
0 that a single decoding time
is not limited
Manual Read
Mode
Trigger level
Low level trigger
Default high level
Appendix B: Common Serial Commands
Fuction
Serial command
Set the baud rate to 9600
7E 00 08 01 00 D9 D3 20 38
Save the settings to the EEPROM
7E 00 09 01 00 00 DE C8
Query baud rate
7E 00 07 01 00 2A 02 D8 0F
After the host sends a serial command to query the baud rate, the reading module will reply to the following
information:
returned messages
Corresponding baud rate
02 00 00 02 C4 09 SS SS
1200
02 00 00 02 71 02 SS SS
4800
02 00 00 02 39 01 SS SS
9600
02 00 00 02 D0 00 SS SS
14400
02 00 00 02 9C 00 SS SS
19200
02 00 00 02 4E 00 SS SS
38400
02 00 00 02 34 00 SS SS
57600
Note: SS SS is the check value.
