19
KR-FELDER-STR.1
A - 6060 HALL in Tirol
AUSTRIA
Tel.: 0043 (0)5223 / 45 0 90
Tax.: 0043 (0)5223 / 45 0 99
Motordaten:
Baujahr / year of constr. / annee de constr. :
A:KW:
HZ:PH:V:
NR. :
TYPE :
info@hammer.at / www.hammer.at
"
!
Bandsaw
N2-35
5.4 Safety break switches
The machine only runs when the end switch in the inside
of the machine frame is engaged by the locking device
! Lock system
" Break switch
Fig. 5-3: Lock system
5.2 Data plate
The data plate displays the following specifications:
• Manufacturer information
• Model designation
• Machine number
• Voltage
• Phases
• Frequency
• Motor power
• Power supply
• Year of construction
• Motor specifications
Fig. 5-2: Data plate
5.3 Automatic braking system
Your machine is equipped with an automatic braking
unit. The brake is a maintenance-free DC braking unit.
All necessary adjustments are done by FELDER KG.
Please contact the FELDER KG service department, if pro-
blems or a fault- function should occur!
Setting up the machine
