Hammer N2-35 - Specific Transport Procedures; Transport with a Crane; Transport with Rolling Carriage

22
!
A
!
Bandsaw
N2-35
6.5.2 Transport with a crane
Fig. 6-2: Transport with a crane
For crane transport only belts may be used.
Hang the straps in position A.
!Belts
Transport, packaging and storage
Attention! Risk of material damage!: Do not lift the machine by its work table, extension frames or hand-
wheels.
Align the straps correctly and check that the machine is properly supported. The machine must be raised slow-
ly and very carefully to prevent the load from slipping.
Accessories Order no.:
Rolling carriage - 503-142
Lifting bar - 500-149
Note:
The rolling carriage and the lifting bar (option) facilitate the task of transporting the machine.
6.5.3 Transport with a rolling carriage
Fig. 6-3: Transport with a rolling carriage
