Operation/room temperature +10 to +40 °C
Storage temperature –10 to +50 °C
The following electrical requirements must be fulfilled:
• Earth the machine using an electrical conductor.
• The voltage regulation in the electricity network must
not exceed ± 10% of the rated voltage.
• The current supply has to be protected against dam-
ages e.g. armoured conduit.
• Connected vacuum hoses have to be earthed to avoid
electrostatic charges.
Total size 800 x 650 x 1900 mm
Package size 780 x 660 x 1900 mm
Net weight 140 kg
Technical data
Cutting height 275 mm
Rip capacity 420 mm
Rip capacity with parallel cutting fence 370 mm
Saw blade length min. 3950 mm
Saw blade length max. 4000 mm
Saw blade width min. 6 mm
Saw blade width max. 20 mm
Saw blade speed 20 m/min
Wheel diameter 440 mm
Table size 420 x 575 x 950 mm
Table tilt left 10°
Table tilt right 22,5°
