15
7. With a sharp hobby knife, carefully cut a 1/8′′ wide slot
which is 1-5/8′′ in length through both the covering and the
balsa wood along the lines which were drawn in Step 5 of this
section. Remove the excess balsa from the slots.
8. Trial fit the aileron tray supports into the slots. It may be
necessary to enlarge the slots slightly to accommodate the
supports.
9. Using a sharp hobby knife, carefully cut through the balsa
wood and the covering along the lines that were drawn in Step 6
of this section. Remove the excess balsa from this hole.
10. Trial fit the aileron servo into the servo tray, as well as into
the hole which was cut in the previous step. Position the servo
so the servo horn is closest to the trailing edge. Depending upon
the dimensions of the aileron servo, it may be necessary to
enlarge either the servo tray or the servo hole slightly.
CONTINUED
Section 3: Installing the Aileron Servo Tray
