17
13. After the epoxy has cured, mix a small amount,
approximately 1/4 oz., of 6-minute epoxy to glue the servo tray
into the wing. Using an epoxy brush, apply the epoxy to the
aileron servo supports. Insert the assembled unit into its
receptacle in the wing. Remove any excess epoxy with a paper
towel and rubbing alcohol. Allow the epoxy to cure.
14. Locate the wing center tape and remove the adhesive
backing. Starting at the rear of the aileron servo tray, wrap the
tape completely around the wing joint seam to the rear of the
servo tray. Gently pulling on the tape while pressing it down
onto the wing will provide a smooth seam. Cut off any excess
tape with a pair of scissors.
CONTINUED
Section 3: Installing the Aileron Servo Tray
