111
Attachment
Unit N·m
Grade
4.6 5.6 6.6 8.8
6 4 5 5 7 6 8 9 12
8 10 12 12 15 14 18 22 29
10 20 25 25 31 29 39 44 58
12 35 44 44 54 49 64 76 107
14 54 69 69 88 83 98 121 162
16 88 108 108 137 127 157 189 252
18 118 147 147 186 176 216 260 347
20 167 206 206 265 245 314 369 492
22 225 284 284 343 343 431 502 669
24 294 370 370 441 441 539 638 850
27 441 519 539 686 637 784 933 1244
Note ·Use entirely 8.8 grade bolt in the important joint position.
