1.3 Electromagnetic brake
The adopted brake of this truck is spring weighted electromagnetic brake. This brake is one-chip
brake, owns two friction surfaces. It can generate strong brake torque through compressed spring
in the state of power off, and electromagnetic induction realizes brake release.
1.Mounting screw
3. Friction disk assembly
5. Friction disk
2.Stator
4.Shaft sleeve
6.Dust cover
Fig. 2-1 Parts of electromagnetic brake
4
5
6
3
1
2
