HANGCHA CBD20-AC1S - Dimension;Service Weight

29
4.3 Dimension/Service Weight
Item
CBD20-AC1
CBD20-AZ3
CBD30-AC1
CBD30-AZ3
CBD20/30-AC1S
CBD20/30-AZ3S
Length L
mm 650 650 650
Width W
mm 201 201 249
Height H
mm 570 570 625
Allowable lightest kg 140 190 260
Allowable heaviest kg 240 270 285
WARNING
Battery weight and dimensions have considerable influence on operational safety of
the truck.
When installing or replacing battery, be sure that battery in the fixed position.
H
L
W
