1.4 Drive system dismantle
1 Open rear hood assembly
2 Remove four fixed bolt of steering rocker arm.
3
Remove wiring connected drive system(like
motor, brake wiring)
4
Remove the connecting pin shaft between
connecting rod and frame.
5 Hoist the drive system.
Assembling order is opposite to the disassembling order.
