2 Hydraulic system
Hydraulic system is mainly composed of hydraulic unit, left/right lifting cylinder, booster cylinder
and rubber tube etc..
1. Hydraulic unit
2. Left lifting cylinder
3. Right lifting cylinder
4. Booster cylinder
5. Pipeline assembly
6. Rubber tube assembly
7. Rubber tube assembly
Fig. 2-6 Hydraulic system
1
2
4
5
3
7
6
7
