81
Model
CPCD30-XW33E-RT
CPCD35-XW33E-RT
Rated capacity
kg
3000
3500
Load centre
distance
mm
500
500
Overall maximum
lift height
mm
3000
3000
Free lift height
mm
145
145
Maximum lift
speed (with load)
mm/s
490
430
Tilt of the mast
F/B
10°/12°
10°/12°
Max travel speed
(without load)
km/h
28
28
Ground clearance
mm
270
270
Min outside turning
radius
mm
2900
2900
Max. Grade ability
(Full load)
%
22
22
Wheel-base
mm
1880
1880
Track (F/R)
mm
1250/1205
1250/1205
Service mass
kg
5120
5380
Overall dimension
(L×W×H)(include forks)
4220×1599×2420
4220×1599×2420
Tyre (F/R)
14.5-17-14PR/2
27×10-12-12PR/2
14.5-17-14PR/2
27×10-12-12PR/2
Battery V/ capacity Ah
12/90
12/90
Diesel engine
Model
YANMAR 4TNE98
Rated
capacity/rpm
42.1kW/2300 r/min
Max torque/rpm
186N·m/1700 r/min
Displacement L
3.319
