HANGCHA CPCD25-XW98E-RT2 - Page 86

82
Model
CPCD25-XW33E-RT
Rated capacity
kg
2500
Load centre
distance
mm
500
Overall maximum
lift height
mm
3000
Free lift height
mm
140
Maximum lift
speed (with load)
mm/s
620
Tilt of the mast
F/B
10°/12°
Max travel speed
(without load)
km/h
26
Ground clearance
mm
240
Min outside turning
radius
mm
2900
Max. Grade ability
(Full load)
%
28
Wheel-base
mm
1880
Service mass
kg
4670
Overall dimension
(L×W×H)(include forks)
4205×1597×2390
Tyre (F/R)
12-16.5-14PR/2, 27×10-12-12PR/2
Battery V/ capacity Ah
12/90
Diesel engine
Model
YANMAR 4TNE98
Rated
capacity/rpm
42.1kW/2300 r/min
Max torque/rpm
186N·m/1700 r/min
Displacement L
3.319
