Oscilloscope Functions
USER’S MANUAL 50
3.12 Zoom In/Out and Move Waveforms
The software will stop updating waveform after the user clicked “Stop” button.
The user can change the waveform display by adjusting the scale and position. When you change
the scale, the waveform display will increase or decrease in size.
The channel reference indicator identifies each waveform on the display. The indicator points to the
reference level of the waveform record.
Zoom In/Out
The user can click “Zoom In/Out” in “Acquire” menu, then left click the mouse button on display
screen to zoom in/out the waveform. Also the user can change Time/Div in Horizontal menu or
in Horizontal panel to zoom in/out the waveform.
Move Waveforms
The user can change “Delay Time” on the Horizontal Panel to move the waveform.
