File browse
EN
Copyright © Qingdao Hantek Electronics Co., LTD Tablet1000 User manual
73
18 File browse
In the main interface, click the [File Browse] icon to enter the file browse menu.
File browse includes: image, reference, CSV, binary, and settings.
Figure 18.1 File browse
Under the oscilloscope interface, select the save type, and file will be saved to store to
the File browse or a U disk in the selected type. If no USB flash drive is connected, the
file is saved in File browse by default. If a USB flash drive is connected, the file is
automatically saved in the USB flash drive.
The files are saved in File browse. Click File browse on the main interface and select the
file to call out.
⚫ Picture: Select the picture to open. The interface of the opened picture is the same
as the interface opened in the Gallery. you can choose the last or next one or delete.
Click Return to return to the gallery interface.
⚫ Reference: The reference waveform file can directly open the reference channel in
the oscilloscope interface, and then call the reference waveform.
⚫ CSV: CSV files cannot be called out directly on the machine. If you save it on a USB
flash drive, you can open it on your computer.
⚫ Binary: Select the binary file to be called out in File browse. The pop-up box will
prompt “Successfully called out”. Return to the oscilloscope interface, you can see
the binary file called out.
⚫ Settings: Select the setting file to be called out in File browse. The pop-up box will
prompt “Successfully called out”. Return to the oscilloscope interface, you can see
the settings file called out.
There are delete and rename options on the right side of the File browse interface.
Delete
⚫ Select the file to delete.
⚫ Click Delete.
⚫ Pop-up: Are you sure you want to delete the file?
⚫ Select Confirm or Cancel.
