Bandwidth | 25 MHz |
---|---|
Channels | 2 |
Vertical Resolution | 8 Bit |
Vertical Sensitivity | 2 mV/div to 10 V/div |
Power Supply | 100-240 V AC, 50/60 Hz |
Multimeter | Yes |
Input Impedance | 1 MΩ |
Display | 7 inch LCD |
Display Resolution | 800 x 480 |
Trigger Modes | Edge, Pulse, Video, Slope |
Connectivity | USB Host, USB Device |
Sample Rate | 1 GS/s |
Timebase Range | 5 ns/div to 50 s/div |
