2 Product features
Product features
⚫ 7-inch industrial TFT-LCD, 800*480 multi-point full touch capacitive touch screen,
completely get rid of mechanical keys, better operation experience.
⚫ Number of channels: 4-channel flat panel oscilloscope: 4 channels +1 AFG channel
(1KHz channel without signal source function).2-channel flat panel oscilloscope: 2
channels +1 AFG channel (1KHz channel without signal source function).
⚫ Analog channel bandwidth: 250MHz Max.
⚫ Maximum sampling rate: 4-channel flat panel oscilloscope: 1GSa/s single channel,
500MSa/s double channel, 250MSa/s three or four channels. 2-channel plate
oscilloscope: 250MSa/s double channel, 125MSa/s single channel.
⚫ Maximum storage depth: 4-channel flat panel oscilloscope: 8Mpts (single channel),
4Mpts (double channel), 2Mpts (three or four channels). 2-channel flat panel
oscilloscope: 8Mpts (single channel), 4Mpts (double channel).
⚫ Vertical sensitivity: 4-channel flat panel oscilloscope: 2mV/div ~ 10V /div.
2-channel flat plate oscilloscope: 10mV/div ~ 10V /div.
⚫ Product classification: only with oscilloscope function of 7 inch flat plate oscilloscope,
with oscilloscope + multimeter function of 7 inch flat plate oscilloscope, with
oscilloscope + multimeter + signal source function of 7 inch flat plate oscilloscope.
⚫ Basic trigger functions: edge, pulse width, video, slope, timeout.
⚫ Up to 42 waveform parameters are automatically measured.
⚫ Various mathematical operations: addition, subtraction, multiplication, division, FFT.
⚫ Standard port: USB port.
⚫ Standard 9V2A/5V3A/12v1.5A charger, data line interface input, and mobile phone
can share a set of charging equipment.
⚫ 4 channel flat panel oscilloscope: built-in 10000mAh removable lithium battery;2
channel flat panel oscilloscope: built-in 5000mAh removable lithium battery.
⚫ With the design of supporting foot, it can be used and put to save working space.
⚫ Quick storage function, one key to save waveform to U disk or internal storage,
convenient and fast.
⚫ New man-machine touch interactive experience, simple and clear UI, without
complex operation, everyone can easily use the professional instrument.
⚫ The 7 "large screen display is the same as that of the desktop, which can be used as
the desktop or handheld.
⚫ Large screen, small volume, the net weight of the whole machine is less than 1Kg,
and mobile phone share charger, convenient to carry on business trips.
TO1000 series of a new generation of handheld flat oscilloscopes, using 7-inch industrial
specification TFT-LCD800*480 resolution LCD screen, support multi-point capacitive
touch operation;With oscilloscope, signal source, multimeter three
functions;Oscilloscope has 4 analog channels or 2 analog channels;Its own signal
source support 25MHz standard waveform output, built-in a variety of arbitrary wave;The
