Tablet1000 User manual Copyright © Qingdao Hantek Electronics Co., LTD
20
8 Power switch
After clicking, the machine shuts down.
9 USB disk icon
Plug in the USB disk memory and the icon will be displayed. If no USB flash drive is
inserted, the icon will not be displayed.
10 Hantek icon
4.5 Touch screen gesture
This instrument is mainly operated directly on the built-in capacitive touch screen,
supporting multi-touch operation, including touching, kneading and dragging. With
simple, convenient, flexible and many other characteristics, providing better operation
experience.
4.5.1 Touching
Tap a menu or function on the screen with your finger as shown in the following picture.
The functions that touching can achieve are:
⚫ Touch the menu on the screen to operate on the menu.
⚫ Touch the virtual keyboard to set the name of an image or file.
⚫ Touch the numeric keypad and set various parameters.
⚫ Touch various keys, such as close, up, down, etc.
Figure 4.12 Touching gesture
4.5.2 Kneading
Move two fingers together or apart. Kneading gestures allow you to zoom in and out of
the waveform. Slide the close fingers apart to enlarge a waveform and slide the
separated fingers closer together to shrink a waveform as the following figure shows.
