Specifications
25
Sensor type
Use range
Decimal point range
Use range
Decimal point range
℃ ℉
Thermoresistor
(R.T.D)
Pt100
Pt
-
0 -200 ~ 640 0 -300 ~ 1180 0
Pt
-
1 -200.0 ~ 640.0 1 -300.0 ~ 1180.0 1
Pt
-
2 -100.00 ~ 150.00 2 -300.0 ~ 1180.0 1
KPt100
KPt
-
0 -200 ~ 500 0 -300 ~ 1000 0
KPt
-
1 -200.0 ~ 500.0 1 -300.0 ~ 1000.0 1
KPT
-
2
-100.00 ~ 150.00 2 -300.0 ~ 1000.0 1
Thermocouple
(T.C)
K
K
-
0 -200 ~ 1370 0 -300 ~ 2500 0
K
-
1 -200.0 ~ 1370.0 1 -300 ~ 2500 0
J -200.0 ~ 1200.0 1 -300 ~ 2300 0
E -200.0 ~ 1000.0 1 -300 ~ 1800 0
T -200.0 ~ 400.0 1 -300 ~ 750 0
R 0.0 ~ 1700.0 1 0 ~ 3100 0
B 0.0 ~ 1800.0 1 0 ~ 3300 0
S 0.0 ~ 1700.0 1 0 ~ 3100 0
L -200.0 ~ 900.0 1 -300 ~ 1300 0
N -200.0 ~ 1300.0 1 -300 ~ 2400 0
U -200.0 ~ 400.0 1 -300 ~ 750 0
Wre 5
-
26 0.0 ~ 2300.0 1 0 ~ 4200 0
PL-II 0.0 ~ 1390.0 1 0 ~ 2500 0
[ Range for the sensor types - RTD, TC ]
Sensor type DCV input range Use range
Decimal point range
VDC
-10.00 - 20.00
Decimal point = 0
: -10000 ~ 20000
Decimal point =
1
: -1000.0 ~ 2000.0
Decimal point = 2 : -100.00 ~ 200.00
Decimal point = 3 : -10.000 ~ 20.000
0 ~ 3
0.00 - 100.00
1.00 - 5.00
0.00 - 30.00
[ Basic channel configuration parameter ]
[ Range for the sensor types - DCV ]
Parameter Initial value Configuration range
Sensor type K-1
Refer to the table of the ranges for sensor types
DCV input upper limit DCV upper limit Within the DCV sensor range
DCV input lower limit DCV lower limit Within the DCV sensor range
Upper limit of the use range Use range (100 %) Use range (0 ~ 100 %)
Lower limit of the use range Use range (0 %) Use range (0 ~ 100 %)
Decimal point location 1 0, 1, 2, 3
Input filter 0 second 0 ~ 120 seconds
Displayed unit °C °C, °F, Ω, V,
㎷
, %, user
User UNITnn Enter the text (up to 6 characters)
( nn : Channel number )
