89
4 - System setup
Settings
Speed Input Settings
This will show sprayer speed in the upper blue bar of the working screen, when spraying.
μ
ATTENTION!
• The Universal Terminal has to be setup to “Sprayer speed”. See “CONTROLLER ISOBUS VT” instruction book.
Choices for Primary Source include:
• Hardi
• Display GPS
• Auxiliary Device
Other Possible Options (not used for HARDI®
sprayers):
• Manual Speed
Primary Source selections to use:
μ
ATTENTION! When “Hardi” option is selected as Primary Source, you may use the VT speed calibration (menu 3.1).
÷
NOTE! If “Display GPS” is selected, the “Hardi” option must be selected as backup source if available.
Hardi Display GPS Auxiliary Device Manual Speed
Trailer sprayer with
SafeTrack/IntelliTrack
Must always use “Hardi” as
speed source as the steering
system cannot use GPS as
speed source.
Not used. Not used. Not used.
Self-Propelled sprayer Can be used. Can be used. Not used. Not used.
SARITOR sprayer Not used. Always select “Display GPS” as
speed source.
Not used. Not used.
Lift mounted sprayer Not used. Can be used. Can use speed input from the
tractor*
Not used.
*Choices for Auxiliary Device Channel include:
• Wheels
• Radar
If you are using a backup radar speed source it is recommended that you calibrate it before the season begins.
• Filtered
This setting is used only as a backup speed source for low pulse ground speed sensors.
Your Specific
Configuration
Speed Input
Primary Source
Hardi
To Next Page
