Hardi NAVIGATOR 3500 Instruction Book

5 - Operation
5.10
TurboFiller rinsing
Rinsing the TurboFiller and chemical containers are done in the
following two ways:
When TurboFiller lid is open: For cleaning empty containers. Put
container over the rotating flushing no
zzle in the middle of the
TurboFiller so that the nozzle is inside the container. Press the Chemical
Container Cleaning lever and TurboFiller suction valve at the same time
to activate the flus
hing nozzle in the middle of the TurboFiller and
empty out the TurboFiller rinsing liquid.
When TurboFiller lid is closed: Use the Chemical Container Cleaning lever to rinse the hopper after fillin
g of chemicals has
ended. Press the Chemical Container Cleaning lever and TurboFiller suction valve at the same time to activate the flushing
nozzle in the middle of the TurboFiller and empty
out the TurboFiller rinsing liquid. Do this 3 times and after last flushing,
then open lid to inspect if the TurboFiller is empty. If not, then close lid again and press TurboFiller suction valve until th
e
TurboFiller is empty.
Quick reference - Operation
In the following diagram, handle positions for different options are described.
*designates an optional function.
